· dust collector filter bag from SHANGHAI SFFILTECH CO., LTD brings the special design to the extreme.
· dust collector filter bag can stand all kinds of strict tests before putting into use.
· Aided by professional team, the service of SFFILTECH is well-known in dust collector filter bag industry.
Material:
aramid needle punched felt are made from the aramid yarn, after needle punched we can get the common 450gsm, 500gsm, 550gsm aramid filter cloth.
There are two kinds of aramid filter cloth used in dust filtration:
1.aramid fiber with aramid scrim
2.Aramid fiber with fiberglass scrim
The aramid filter media common treatment:
Singed, calendered, heat set or water&oil repellent, anti-static, PTFE membrane/coating
The diameter of the filter bag is: diameter 100mm, 125mm, 130mm, 150mm, 180mm, 250mm etc.
Any length is available. Special size is customize.
The aramid bag filter process Method: sewing or welded
Advantages:
Fire resistant
High temperature resistant
Working temperature: 204 degree
Max temperature: 240 degree
Excellent alkali resistance
Good acid resistance
Good organic solvents resistance
Excellent abrasion resistance
Good hydrolysis stability
Dust collector filter bag:
Since every filter has its own characteristics and parameters,
when we chose filter material for dust collector filter bags,
we have to know the following parameters: temperature, humid,
dust diameter, gas chemical properties, dust abrasive, filter's mechanical parameters.
Generally, SFF dust collector filter bags are widely used in industrial waste gas filtration, useful dust, high temperature gas filters.
Shanghai filter bag factory provides you good solution according to dust characteristics, help you chose good filter material to achieve best filtering effective
Specification:
Specs And Features
Material Nomex/Nomex Thickness 1.1
Weight(g/sqm) 450 Density(g/cm³) 1.38 Air Permeability(m³/m²/min) 12
Warp Tensile Strength 1000 Weft Tensile Strenght 1200 Moisture Regain 4.50%
(N/5x20cm) (N/5x20cm) (20℃ And 65% r. humidity)
Warp Elongation(%) 20 Weft Elongation(%) 40 Support Combustion No
Continuous Dry 204 Continuous Moist 204 Max Short Dry Heat 240
Heat Operation(℃) Heat Operation(℃) Surge(Short Term)(℃)
Biological(Mildew, Bacteria) No Effect Alkalis Resistance good Mineral Acids Resistance fair
Resistance
Organic Acids Resistance fair Oxidising Agents Resistance poor Organic Solvents Resistance Excellent
Finishing Singeing-calendering-heat setting
Product Applications Chemical/ Steel/Waste Incineration/Thermoelectricity/Construction Material
Usage Air Filter
Type Filter Felt
Specialized in supplying
1.Needle puched felt 2.Woven filtration fabric 3.Filter bags 4.Filter cages 5.Filter tubing automatic production line
Application:
High temperature condition, dust collection and gas collection engineering for asphalt mixing plant, cement plant, power plant, steel mill, smelting plant, etc industrial dust collection.
Engaged in creating a clean and fresh environment for people, Sffiltech is specialized in aramid filter bag. As one of the best manufacturers and suppliers, we can assure you the best quality and stable performance of our custom products. Please rest assured to buy.
Company Features
· Throughout our long history, SHANGHAI SFFILTECH CO., LTD has been acknowledged as one of the leaders in manufacturing dust collector filter bag. We have grown to become a respected manufacturer.
· The factory has a Target Operating Model System (TOMS) which helps the factory define what specific resources and capabilities it needs. This will help realize the company's defined vision, goals, and objectives for its customers. Our factory runs with a strict supply chain management system. This system guarantees the day-to-day flow of goods and raw materials, which in return helps the factory regulate and coordinate production plans. The company has a powerful R&D team with mature technologies and abundant experience. Their research and technological strength in the products reach the internationally recognized level.
· SHANGHAI SFFILTECH CO., LTD is determined to touch billions of lives with its dust collector filter bag. Get info!
Product Details
To better learn about dust collector filter bag, SFFILTECH will provide detailed pictures and detailed information in the following section for your reference.
Enterprise Advantages
Our company has a strong technical team engaged in independent innovation. Meanwhile, we actively strengthen cooperation with domestic research institutes. Apart from that, we recruit well-known experts in the industry as senior consultants. All that provides strong technical support for our development.
Our company insists on the service concept of 'customer first' and can supply customers with stable and high-quality services.
SFFILTECH always believes that details determine the brand and innovations change destiny. We are committed to providing consumers with better products and more professional services. We aim to become a domestic leading company with large influence.
Since its inception in our company has a history of development for years. During this time, we have been continuously exploring new models and new roads in order to better adapt to the special environment in the historical exchange period.
Our company actively explores product sales channels and establishes a sound marketing network. Our products are not only sold to many provinces and cities in China, but also exported to East Asia and South Asia.
