Nylon Mesh Filter Fabric by SFFILTECH 1
Nylon Mesh Filter Fabric by SFFILTECH 1

Nylon Mesh Filter Fabric by SFFILTECH

Inquiry
Send your inquiry

Product details of the nylon mesh filter fabric


Quick Overview

The unique design makes SFFILTECH nylon mesh filter fabric stand out among similar products. The product has been approved and certified by many international certifications. It is proven that the product has wide application prospects.


Product Information

To better learn about nylon mesh filter fabric, SFFILTECH will provide detailed pictures and detailed information in the following section for your reference.

Material:

polyester filter bag are made of 100% filament polyester fiber,after needle punched, singed heat set calender for the raw polyester filter felt material, then polyester filter felt can be sewn into polyester filter bags.

Feature:

1.Operation temperature 150 Deg c,

2.the max surge is 150 deg c.

3.good anti-acid, good  anti-alkali ,good hydrolysis stability

4.Mean Air Permeability: 10-15 m3/m2/min@12.7mmH2O

5.It is the cheapest filter media in the bag filter filtration field. Polyester bag filter is the most popular items in the bag house system.Available Finish: singed,calendar,heat set PTFE membrane,W/O,anti-static treatment.

Advantage:

Polyester bag filters Breaking Elongation is less than 20% for MD and 40% for CMD,low dry shrinkage, can work well in the 130 deg C. the material is cheaper than other material, so widely used in a lot of bag house system.

Techinical data

Shanghai Filterbag Factory Co., Ltd

 500gsm polyester needle punched felt+water&oil repellent

Construction

Needle felt

Fibre   Composition

Polyester

Scrim   Composition

Polyester

Felt Area Weight

500g/m2(±5%)

Thickness

1.8-1.9mm

Mean Air   Permeability

10-15   m3/m2/min@12.7mmH2O

Breaking   Strength-MD(warp)

900    N / 125px

Breaking   Strength-CMD(weft)

1300 N /   125px

Breaking   Elongation( N/125px)-MD(warp)

20%

Breaking   Elongation( N/125px)-CMD(weft)

40%

Dry   Shrinkage     MD(130℃warp)

<1.5 %

Dry   Shrinkage     CMD(130℃weft)

<1.5 %

Operating   Temperatures

<130 deg C

Recommended   Maximum Continuous

130 deg C

Recommended   Maximum Surge

150 deg C

Finish

Heat set, singed, calendared W/O Repellent

Application:

Polyester filter bag widely used in mine, limestone, cement, iron and steel industries,alumina delivery, electrolytic aluminum, non-ferrous metal production, wood processing, food processing and pharmacy industry.
