Product details of the pe mesh cloth


Product Information

Strong design attitude and a personality are added to pe mesh cloth. The offered product is equipped with a long service life and has reliable functions. SHANGHAI SFFILTECH CO., LTD has world-wide sales network and manufacturing base.

Material:

polyester filter bag are made of 100% filament polyester fiber,after needle punched, singed heat set calender for the raw polyester filter felt material, then polyester filter felt can be sewn into polyester filter bags.

Feature:

1.Operation temperature 150 Deg c,

2.the max surge is 150 deg c.

3.good anti-acid, good  anti-alkali ,good hydrolysis stability

4.Mean Air Permeability: 10-15 m3/m2/min@12.7mmH2O

5.It is the cheapest filter media in the bag filter filtration field. Polyester bag filter is the most popular items in the bag house system.Available Finish: singed,calendar,heat set PTFE membrane,W/O,anti-static treatment.

Advantage:

Polyester bag filters Breaking Elongation is less than 20% for MD and 40% for CMD,low dry shrinkage, can work well in the 130 deg C. the material is cheaper than other material, so widely used in a lot of bag house system.

Techinical data

                              Shanghai Filterbag Factory Co., Ltd                       www.sffiltech.comPe Mesh Cloth by SFFILTECH 3

500gsm polyester needle punched felt+water&oil repellent

Construction

Needle felt

Fibre   Composition

Polyester

Scrim   Composition

Polyester

Felt Area Weight

500g/m2(±5%)

Thickness

1.8-1.9mm

Mean Air   Permeability

10-15   m3/m2/min@12.7mmH2O

Breaking   Strength-MD(warp)

900    N / 125px

Breaking Strength-CMD(weft)

1300 N /   125px

Breaking   Elongation( N/125px)-MD(warp)

20%

Breaking   Elongation( N/125px)-CMD(weft)

40%

Dry   Shrinkage     MD(130℃warp)

<1.5 %

Dry   Shrinkage     CMD(130℃weft)

<1.5 %

Operating   Temperatures

<130 deg C

Recommended   Maximum Continuous

130 deg C

Recommended   Maximum Surge

150 deg C

Finish

Heat set,   singed, calendared W/O Repellent

Application:

Polyester filter bag widely used in mine, limestone, cement, iron and steel industries,alumina delivery, electrolytic aluminum, non-ferrous metal production, wood processing, food processing and pharmacy industry.
